  • Double Offset Butterfly Valve – Model 9900

    • Double Offset Butterfly Valve – Model 9900

    Design Features

    Size:

    2” to 160” (50mm to 4000mm)

     Rating:

    Class 150 to Class 600

     Features:
    • Class900 & above valves on request
    • Soft, Metal & Fire Safe Seat Design
    • Blow Out Proof Stem
    • Low Emission & Live Load Design
    • Extended Bonnet Design
    • Bi-Direction, Tight Shut off
    • Wafer, Lug & Flange Type Design
     Operations:

    Bare Stem, Manual & Actuation

    Reference Standards

    Design:

    ASMEB16.34, API609

     Face to Face :

    API 609 Cat. B, EN558,

     Drilling:

    ASME B16.5 & B16.47, EN1092

     Testing:

    API 598, FCI 70.2, ISO 5208

     FIRE SAFETY DESIGN:

    API 607 & API 6FA

     AWWA:

    AWWA C504, & C207

     Bonnet Design:

    BS 6364, MSS SP-134

     Top Work:

    ISO 5211

     Special:

    NACE MR 01-75

     NDT:

    As per Requirements
